Спойлер крыши 2 HOWO (Хово) HOWO A7 84 Гр. Оперение
Спойлер крыши
| Номер на рисунке | Название в интернет-магазине | Остаток | Артикул | Кол-во в автомобиле | Название 1 | Название 2 | Примечание 1 | Примечание 2 |
|---|
| Номер на рисунке | Название в интернет-магазине | Остаток | Артикул | Кол-во в автомобиле | Название 1 | Название 2 | Примечание 1 | Примечание 2 |
|---|---|---|---|---|---|---|---|---|
| 1 | WG1662870022 | 1 | 导流罩 | roof Spoiler | ||||
| 2 | WG1662870052 | 1 | 导流罩左前连接板 | left front link plate for roof Spoiler | ||||
| 3 | WG1662870053 | 1 | 导流罩右前连接板 | right front link plate for roof Spoiler | ||||
| 4 | WG1662870054 | 2 | 垫片 | Section | ||||
| 5 | WG1662870023 | 2 | 导流罩前支架座总成 | member front for roof Spoiler | ||||
| 6 | Q40208 | 16 | 大垫圈 | Wpsher | ||||
| 7 | Q218B0825 | 8 | 内六角圆柱头螺钉 | hexagon Screw | ||||
| 8 | Q40308 | 8 | 弹簧垫圈 | spring washer | ||||
| 9 | Q340B08 | 8 | I型六角螺母 | hexagon nut | ||||
| 10 | Q173B1065 | 2 | 六角头螺杆苛孔螺栓 | hexagon bolt | ||||
| 11 | Q40210 | 4 | 大垫圈 | Washer | ||||
| 12 | Q5002532 | 2 | 开口销 | Forelock | ||||
| 13 | Q381B10 | 2 | 1型六角开槽螺母-细牙-A和B级 | hexagon nut | ||||
| 14 | WG1662870042 | 2 | 导流罩后连接支架 | member rear for roof Spoiler | ||||
| 15 | WG1662870026 | 1 | 导流罩后支架总成 | member rear for roof Spoiler | ||||
| 16 | AZ1664870055 | 16 | 橡胶垫 | Cushion of rubber | ||||
| 17 | Q150B0830 | 16 | 六角头螺栓 | hexagon bolt | ||||
| 18 | Q40308 | 16 | 弹簧垫圈 | spring washer | ||||
| 19 | Q40208 | 16 | 大垫圈 | Washer | ||||
| 20 | Q150B1030 | 2 | 六角头螺栓 | hexagon bvoIt | ||||
| 21 | Q40310 | 2 | 弹簧垫圈 | spring washer | ||||
| 22 | Q40210 | 4 | 大垫圈 | Washer | ||||
| 23 | Q150B0820 | 4 | 六角头螺栓 | hexagon bolt | ||||
| 24 | Q40308 | 4 | 弹资垫圈 | spring washer | ||||
| 25 | Q40208 | 4 | 大垫圈 | Washer | ||||
| 26 | WG1662870044 | 2 | 连接方管 | link tube | ||||
| 27 | Q173B1065 | 4 | 六角头嫘杆带孔嫘栓 | hexagon bolt | ||||
| 28 | Q40210 | 2 | 大垫圈 | Washer | ||||
| 29 | Q381B10 | 4 | 1型六角幵槽螺母-细牙-A和B级 | hexagon nut | ||||
| 30 | Q5002532 | 4 | 开口销 | Forelock | ||||
| 31 | WG1662870034 | 1 | 左弯管支架 | member left | ||||
| 32 | WG1662870035 | 1 | 右弯管支架 | member right | ||||
| 33 | Q150B1030 | 4 | 六角头螺栓 | hexagon bolt | ||||
| 34 | Q40310 | 4 | 弹簧垫圈 | spring washer | ||||
| 35 | Q40210 | 4 | 大垫圈 | Washer | ||||
| 36 | Q150B0820 | 2 | 六角头螺栓 | hexagon bolt | ||||
| 37 | Q40308 | 2 | 弹资垫圈 | spring washer | ||||
| 38 | Q40208 | 2 | 大垫圈 | Washer |
